Now that the TAs have worked out an office hours schedule to their satisfaction, they want to optimize how exams are graded. Previously a lot of dice and a magic 8-ball were used. The TAs have a new idea in mind, and your job is to write a program to help schedule that new grading idea.
Any changes to this page will be put here for easy reference. Typo fixes and minor clarifications are not listed here. So far there aren’t any significant changes to report.
The TAs want to form a number of “teams” to grade the exams, with each of the TAs on a given team grading a different question. As there are more TAs than questions on any given exam, there will be multiple TAs on a given question, but exactly one TA per question on each team. Each exam has to pass through each of the questions, in order, before it is fully graded. However, any given exam can switch between the teams. We’ll assume, for all input cases, that the number of TAs is an integer multiple, greater than 0, of the number of questions on the exam.
For example, let us assume that there are 18 TAs and 6 exam questions. Three TAs will grade each question. We can put them into three teams so that one TA for each question is team “A”, one of each is team “B”, and one of each is team “C”. (We’ll use numbers starting from 0 in our input below, but using letters for teams will make it easier to walk through this example.) This would look like the following:
When any of the question 1 graders (A1, B1, or C1) becomes available, they will take the next exam, and it will proceed through the questions, in order through the team, until it is graded. (We are assuming it must be in order since sometimes answers are dependent on previous answers).
However, this is not optimal. When an exam is moving through the diagram, and waiting for its next question to be graded, a grader from a different team might be faster. For example, an exam could take a faster path by switching through the teams, as shown by the dashed lines:
There are a number of other factors to consider:
We are looking for the fastest time to grade the exam.
The problem, then is to determine the fastest time to grade a single exam. To make this problem viable, we will assume that all the TAs are idle, and any TA is available to grade their respective question at any time.
We will continue the example from the diagrams above, with 18 TAs and 6 exam questions. Thus, there are 3 teams.
Each problem will be given the number of teams, the number of TAs, and the values in both g(t, q) (the time it takes for the TA on team t to grade question q) and x(t, q) (the transfer time to transfer a question from team t to any other team who is grading question q).
Let f(t, q) be the fastest time that team t could have graded question q.
For example, consider determining the fastest time that team B could have graded question 3. There are three possibilities:
The final result for f(B, 3) is the minimum of those three values.
Note that there could be more than three teams. Also, the teams are represented by numbers (starting from 0), but it’s easier to explain using letters for teams. In the above example, A=0, B=1, and C=2.
The final answer is the minimum of the times to have graded the last question. In this example, that is the minimum of f(A, 6), f(B, 6), and f(C, 6).
Let’s assume we still have 18 TAs and 6 exam questions. Note that this example does NOT correspond to the diagrams above.
The cost for the teams to grade each question is as follows (this is the g array).
| Team | Q1 | Q2 | Q3 | Q4 | Q5 | Q6 |
|---|---|---|---|---|---|---|
| A | 7 | 11 | 6 | 11 | 9 | 7 |
| B | 9 | 15 | 12 | 15 | 11 | 14 |
| C | 14 | 5 | 11 | 12 | 5 | 6 |
The cost to transfer an exam from one team to another is as follows (this is the x array). Note that there is no transfer to question 1.
| Team | to Q2 | to Q3 | to Q4 | to Q5 | to Q6 |
|---|---|---|---|---|---|
| A | 6 | 7 | 5 | 6 | 5 |
| B | 8 | 8 | 7 | 6 | 7 |
| C | 9 | 8 | 9 | 7 | 7 |
The cost to grade question 1 by each of the teams is just the cost to grade that question, as there is no transferring at that point, so it is 7, 8, and 14, respectively, for teams A, B, and C.
Consider the cost for question 2 to be graded by team C. Possibilities:
The minimum of these is 18, which is the least amount of time taken when team C has graded question 2. This means that, for team C to have graded question 2, the fastest path was for team A to have graded question 1 and then the test was transferred to team C to grade question 2.
For this homework, we are NOT providing you with skeleton code that handles reading in of the input. You should look at the previous two homeworks for examples how to do so: PA1: Driving Directions (md) and PA2: Office Hours (md).
All input is read in from standard input (not a file). All values read in are non-negative integers that will fit into a signed int variable.
The first line of the file will contain the single positive integer 1 ≤ c ≤ 105, the number of test cases in the file.
The first line of each test case will contain two values n and q, space separated, which is the number of TAs and exam questions, respectively. It will always be the case that n is a positive integer multiple of q. The number of grading teams, then, would be n/q.
The next line will contain the time taken to grade array (array g in the description above). This will be presented as a single line of space-separated values in row-major order (the first row (the time for the “A” team to grade), followed by the second row (the time for the “B” team to grade), followed by the third row, etc.).
The next line will contain the transfer time array (array x in the description above). This will be presented as a single line of space-separated values in row-major order. Note that this array has one fewer columns than the g array.
The first test case is the specific example shown above. This file is available as example.in.
3
18 6
7 11 6 11 9 7 9 15 12 15 11 14 14 5 11 12 5 6
6 7 5 6 5 8 8 7 6 7 9 8 9 7 7
25 5
8 10 8 6 12 8 9 15 7 11 15 6 7 15 8 9 6 12 11 13 11 6 13 10 10
8 7 6 9 7 8 5 10 9 7 8 5 9 7 8 7 10 7 9 8
48 12
12 11 14 11 5 13 14 14 11 8 15 9 11 6 11 11 11 8 13 7 7 13 13 6 7 12 8 10 7 13 10 12 9 13 5 7 8 9 7 6 8 6 14 5 11 7 6 7
10 6 10 6 10 10 9 5 6 10 10 9 8 8 10 9 5 9 7 6 10 9 9 7 7 6 7 6 7 10 6 7 9 9 10 6 6 8 10 6 8 10 8 10Other, larger, test cases are described below.
Each test case will output a single integer, which is the minimum cost to grade that exam.
51
44
94This assignment must be a dynamic programming solution. We have some very large test cases, and they will time out with any other type of solution. Some of those test cases are given below.
There are some assumptions that you may and may not make:
int variableThere a few large test cases available in Canvas’ Files. They are contained in a zip file named pa4-examples.zip. The files therein are as follows.
We give the times so you can see, relatively, how long they might take – obviously the speed on your computer will vary. These were using a Python solution, and Java tends to be faster than Python (everything is faster than Python). It’s fine if your program is slower, as long as the second-to-last test case below (pa4-example-1M-1k.in) runs in a minute or less.
pa4-example-1k-10.in: 1,000 TAs and 10 questions, which means 100 teams; the answer is 64, and it took about 0.05 seconds to compute.pa4-example-10k-100.in: 10,000 TAs and 100 questions, which means 100 teams; the answer is 739, and it took about 0.1 seconds to compute.pa4-example-100k-1k.in: 100,000 TAs and 1,000 questions, which means 100 teams; the answer is 7362, and it took about 1 second to compute.pa4-example-1M-10k.in: 1 million TAs and 10,000 questions, which means 100 teams; the answer is 73511, and it took about 8 seconds to compute.pa4-example-1M-1k.in: 1 million TAs and 1,000 questions, which means 1,000 teams; the answer is 6754, and it took about 80 seconds to compute.
If your program does not implement a dynamic programming algorithm, at least one of those cases will time out when we run it (not counting the last one).
We will run your program as follows:
cat example.in | python3 pa4.pyor:
cat example.in | java PA4This takes the output of what is on the left (cat example.in, whose output is the contents of the example.in file) and uses it as the input to what is on the right. This version should work in all platforms (Windows, MacOS, and Linux).
You will submit your completed pa4.py or PA4.java file to Gradescope. There will be a small set of acceptance tests that are NOT COMPREHENSIVE. These acceptance tests are the test cases in example.in file. It’s up to you to comprehensively test your code. The acceptance tests just verify that you are reading the input correctly and providing the expected output.
